222 series
Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts…
Product Description
Product Details
Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.
Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance
Detailed pictures
Parameter table
| Bearing Number | d mm | D mm | B mm |
| 22205 EK | 25 | 52 | 18 |
| 22206 EK | 30 | 62 | 20 |
| 22207 EK | 35 | 72 | 23 |
| 22208 EK | 40 | 80 | 23 |
| BS2-2208-2RSK/VT143 | 40 | 80 | 28 |
| 22209 EK | 45 | 85 | 23 |
| BS2-2209-2RSK/VT143 | 45 | 85 | 28 |
| 22210 EK | 50 | 90 | 23 |
| BS2-2210-2RSK/VT143 | 50 | 90 | 28 |
| 22211 EK | 55 | 100 | 25 |
| BS2-2211-2RSK/VT143 | 55 | 100 | 31 |
| 22212 EK | 60 | 110 | 28 |
| BS2-2212-2RSK/VT143 | 60 | 110 | 34 |
| 22213 EK | 65 | 120 | 31 |
| BS2-2213-2RSK/VT143 | 65 | 120 | 38 |
| 22214 EK | 70 | 125 | 31 |
| BS2-2214-2RSKVT143 | 70 | 125 | 38 |
| 22215 EK | 75 | 130 | 31 |
| BS2-2215-2RSK/VT143 | 75 | 130 | 38 |
| 22216 EK | 80 | 140 | 33 |
| BS2-2216-2RSK/VT143 | 80 | 140 | 40 |
| 22217 EK | 85 | 150 | 36 |
| BS2-2217-2RSK/VT143 | 85 | 150 | 44 |
| 22218 EK | 90 | 160 | 40 |
| BS2-2218-2RSK/VT143 | 90 | 160 | 48 |
| 22219 EK | 95 | 170 | 43 |
| 22220 EK | 100 | 180 | 46 |
| BS2-2220-2RS5K/VT143 | 100 | 180 | 55 |
| 22222 EK | 110 | 200 | 53 |
| 23122-2CS5K/VT143 | 110 | 180 | 56 |
| 23222 CCK/W33 | 110 | 200 | 69.8 |
| 23222-2CS5K/VT143 | 110 | 200 | 69.8 |
| BS2-2222-2RS5K/VT143 | 110 | 200 | 63 |
| 22224 EK | 120 | 215 | 58 |
| BS2-2224-2RS5K/VT143 | 120 | 215 | 69 |
| 22226 EK | 130 | 230 | 64 |
| BS2-2226-2CS5K/VT143 | 130 | 230 | 75 |
| 22228 CCK/W33 | 140 | 250 | 68 |
| 22228-2CS5K/VT143 | 140 | 250 | 68 |
| 22230 CCK/W33 | 150 | 270 | 73 |
| 22230-2CS5K/VT143 | 150 | 270 | 73 |
| 22232 CCK/W33 | 160 | 290 | 80 |
| 22232-2CS5K/VT143 | 160 | 290 | 80 |
| 22234 CCK/W33 | 170 | 310 | 86 |
| 22234-2CS5K/VT143 | 170 | 310 | 86 |
| 22236 CCK/W33 | 180 | 320 | 86 |
| 22236-2CS5K/VT143 | 180 | 320 | 86 |
| 22238 CCK/W33 | 190 | 340 | 92 |
| 22238-2CS5KVT143 | 190 | 340 | 92 |
| 22240 CCK/W33 | 200 | 360 | 98 |
| 22240-2CS5K/VT143 | 200 | 360 | 98 |
| 22244 CCK/W33 | 220 | 400 | 108 |
| 22244-2CS5K/VT143 | 220 | 400 | 108 |
| 22248 CCK/W33 | 240 | 440 | 120 |
| 22252 CACK/W33 | 260 | 480 | 130 |
| 22252 CCK/W33 | 260 | 480 | 130 |
| 22256 CCK/W33 | 280 | 500 | 130 |
| 22260 CCK/W33 | 300 | 540 | 140 |
| 22264 CCK/W33 | 320 | 580 | 150 |
| 22272 CAK/W33 | 360 | 650 | 170 |
