Round Bore
BORET agricultural bearings will keep your equipment in line. We work with the top manufacturers to offer agricultural radial ball bearings, agricultural disc harrow bearings and agricultural tapered bearings that provide tight, efficient control over machine operations…
Product Description
BORET agricultural bearings will keep your equipment in line. We work with the top manufacturers to offer agricultural radial ball bearings, agricultural disc harrow bearings and agricultural tapered bearings that provide tight, efficient control over machine operations.
Round Bore Cylindrical /Spherical O.D. Disc Harrow Bearings:
| Round bore | |||||
| Bearing Number | Type | d mm | D mm | B mm | C mm |
| 203KRR5 | Cylinfrical | 13.081 | 47.000 | 18.288 | 12.000 |
| 203KRR2 | Cylinfrical | 16.256 | 47.000 | 18.288 | 12.000 |
| 203KRR6 | Cylinfrical | 16.256 | 47.000 | 18.288 | 12.000 |
| 203KRR7 | Cylinfrical | 17.000 | 47.000 | 16.612 | 12.000 |
| 203PP8 | Cylinfrical | 12.964 | 52.000 | 34.925 | 15.000 |
| 205KRR6 | Cylinfrical | 13.081 | 52.000 | 34.925 | 15.000 |
| 205PP10 | Cylinfrical | 16.000 | 52.000 | 34.925 | 15.000 |
| 205PP12* | Cylinfrical | 16.129 | 52.000 | 38.100 | 15.000 |
| 205PP9 | Cylinfrical | 19.202 | 52.000 | 34.925 | 15.000 |
| 205PP11 | Cylinfrical | 25.400 | 52.000 | 30.175 | 15.000 |
| 206KP2 | Cylinfrical | 30.000 | 62.000 | 24.000 | 16.000 |
| 206KRR8 | Cylinfrical | 30.000 | 62.000 | 24.000 | 17.000 |
| 206KR7 | Cylinfrical | 30.000 | 62.000 | 24.000 | 16.000 |
| 207KRR14 | Cylinfrical | 31.826 | 72.000 | 25.000 | 17.000 |
| 207KRR3 | Cylinfrical | 35.000 | 72.000 | 25.000 | 17.000 |
| W208PP10 | Cylinfrical | 38.113 | 80.000 | 42.875 | 21.000 |
| W208PP2 | Cylinfrical | 38.113 | 80.000 | 42.875 | 30.175 |
| 208KRR4 | Cylinfrical | 38.892 | 80.000 | 27.508 | 21.000 |
| 208KR4 | Cylinfrical | 38.892 | 80.000 | 27.508 | 21.000 |
| 208KRR2 | Cylinfrical | 40.000 | 80.000 | 27.000 | 21.000 |
| 209KRR3 | Cylinfrical | 45.000 | 85.000 | 27.000 | 21.000 |
| GW210PP3 | Cylinfrical | 35.725 | 90.000 | 27.000 | 30.175 |
| W210PP8 | Cylinfrical | 38.862 | 90.000 | 27.000 | 30.175 |
| W210PP2 | Cylinfrical | 49.225 | 90.000 | 30.175 | 30.175 |
| GW210PP9 | Cylinfrical | 49.403 | 90.000 | 30.175 | 23.000 |
| 210KRR2 | Cylinfrical | 50.000 | 90.000 | 30.175 | 22.000 |
| GW211PP4 | Cylinfrical | 42.164 | 100.000 | 36.525 | 33.325 |
| GW211PP37 | Cylinfrical | 45.212 | 100.000 | 30.000 | 33.325 |
| W211PP2 | Cylinfrical | 55.575 | 100.000 | 33.325 | 33.325 |
| GW211PP2 | Cylinfrical | 55.575 | 100.000 | 44.450 | 33.325 |
| GW214PP3 | Cylinfrical | 68.278 | 125.000 | 33.325 | 39.675 |
| W214PP2 | Cylinfrical | 70.000 | 125.000 | 33.325 | 39.675 |
| GW214PP2 | Cylinfrical | 70.000 | 125.000 | 68.275 | 39.675 |
| W315PP2 | Cylinfrical | 76.372 | 160.000 | 39.675 | 67.770 |
| 205PPB7* | Spherical | 23.826 | 52.000 | 34.720 | 15.000 |
| G205PPB7* | Spherical | 23.826 | 52.000 | 34.720 | 15.000 |
| 206KRRB9 | Spherical | 25.413 | 62.000 | 24.000 | 16.000 |
| 206KRRB3 | Spherical | 28.588 | 62.000 | 24.000 | 16.000 |
| 207KRRB10 | Spherical | 31.763 | 72.000 | 27.000 | 17.000 |
| W208PPB7 | Spherical | 30.175 | 80.000 | 30.175 | 18.000 |
| W208PPB4 | Spherical | 30.175 | 80.000 | 30.175 | 30.175 |
| 208PPB5 | Spherical | 36.525 | 80.000 | 22.000 | 22.000 |
| W208PPB10 | Spherical | 38.113 | 80.000 | 42.875 | 21.000 |
| W208PPB2 | Spherical | 38.113 | 80.000 | 42.875 | 18.000 |
| W208PPB23 | Spherical | 38.113 | 80.000 | 42.875 | 30.175 |
| W209PPB4 | Spherical | 39.000 | 85.000 | 30.175 | 30.175 |
| GW209PPB4 | Spherical | 39.000 | 85.000 | 30.175 | 30.175 |
| GW209PPB12 | Spherical | 44.831 | 85.000 | 42.850 | 22.000 |
| W209PPB10 | Spherical | 45.000 | 85.000 | 36.525 | 22.000 |
| W209PPB2 | Spherical | 45.000 | 85.000 | 30.175 | 30.175 |
| GW209PPB2 | Spherical | 45.000 | 85.000 | 30.175 | 30.175 |
| W209PPB11 | Spherical | 45.237 | 85.000 | 36.525 | 22.000 |
| GW209PPB11 | Spherical | 45.237 | 85.000 | 36.525 | 22.000 |
| GW210PPB3 | Spherical | 35.725 | 90.000 | 30.175 | 30.175 |
| W210PPB5 | Spherical | 45.339 | 90.000 | 30.175 | 30.175 |
| GW210PPB5 | Spherical | 45.339 | 90.000 | 30.175 | 30.175 |
| W210PPB2 | Spherical | 49.225 | 90.000 | 30.175 | 30.175 |
| GW210PPB2 | Spherical | 49.225 | 90.000 | 30.175 | 30.175 |
| W210PPB9 | Spherical | 49.400 | 90.000 | 36.525 | 23.000 |
| GW211PPB4 | Spherical | 42.160 | 100.000 | 33.325 | 33.325 |
| GW211PPB13 | Spherical | 45.339 | 100.000 | 33.325 | 25.000 |
| GW211PPB10 | Spherical | 49.225 | 100.000 | 33.325 | 33.325 |
| GW211PPB14 | Spherical | 51.181 | 100.000 | 33.325 | 25.000 |
| W211PPB2 | Spherical | 55.575 | 100.000 | 33.325 | 33.325 |
| W211PPB4 | Spherical | 55.575 | 100.000 | 55.500 | 33.325 |
| GW211PPB8 | Spherical | 55.575 | 100.000 | 33.325 | 25.000 |
| GW211PPB2 | Spherical | 55.575 | 100.000 | 33.325 | 33.325 |
| GW211PPB9 | Spherical | 55.753 | 100.000 | 39.675 | 25.000 |
| GW211PPB21 | Spherical | 45.340 | 101.067 | 53.980 | 33.909 |
| GW214PPB3 | Spherical | 49.225 | 125.000 | 39.675 | 39.675 |
| GW214PPB6 | Spherical | 68.278 | 125.000 | 68.263 | 28.000 |
| W214PPB2 | Spherical | 70.000 | 125.000 | 39.675 | 39.675 |
| GW214PPB5 | Spherical | 70.000 | 125.000 | 61.925 | 39.675 |
| GW214PPB2 | Spherical | 70.000 | 125.000 | 39.675 | 39.675 |
| W214PPB9 | Spherical | 70.256 | 125.000 | 44.500 | 28.000 |
| GW214PPB9 | Spherical | 70.256 | 125.000 | 44.500 | 28.000 |
| GW216PPB3 | Spherical | 76.450 | 140.000 | 63.500 | 30.000 |
