Single row face-to-face series
Tapered roller bearings arranged face-to-face (X-arrangement, load lines diverge towards the bearing axis) accommodate high radial loads and axial loads in both directions. The precision manufactured intermediate ring between the outer rings enables a defined internal clearance or preload to be achieved when mounted…
Product Description
Product Details
tapered roller bearings arranged face-to-face (X-arrangement, load lines diverge towards the bearing axis) accommodate high radial loads and axial loads in both directions. The precision manufactured intermediate ring between the outer rings enables a defined internal clearance or preload to be achieved when mounted. Matched tapered roller bearings are typically used in gearboxes, hoisting equipment, rolling mills, and machines in the mining industry.
High radial load carrying capacity
Designed for axial loads in both directions
Relatively high stiffness
Surface finish on the contact surfaces of the rollers and raceways that enhances operational reliability
Detailed pictures
Parameter table
| Bearing Number | d mm | D mm | T mm |
| 31305 | 25 | 62 | 36.5 |
| 31306 | 30 | 72 | 41.5 |
| 32206 | 30 | 62 | 42.5 |
| 31307 | 35 | 80 | 45.5 |
| 31308 | 40 | 90 | 50.5 |
| 31309 | 45 | 100 | 54.5 |
| 30210 | 50 | 90 | 43.5 |
| 31310 | 50 | 110 | 58.5 |
| 32010 | 50 | 80 | 40 |
| 30311 | 55 | 120 | 63 |
| 31311 | 55 | 120 | 63 |
| 31312 | 60 | 130 | 67 |
| 31313 | 65 | 140 | 72 |
| 31314 | 70 | 150 | 76 |
| 32014 | 70 | 110 | 50 |
| 33014 | 70 | 110 | 62 |
| 31315 | 75 | 160 | 80 |
| 32215 | 75 | 130 | 66.5 |
| 33015 | 75 | 115 | 62 |
| 33115 | 75 | 125 | 74 |
| 31316 | 80 | 170 | 85 |
| 32016 | 80 | 125 | 58 |
| 32216 | 80 | 140 | 70.5 |
| 33116 | 80 | 130 | 74 |
| 31317 | 85 | 180 | 89 |
| 32017 | 85 | 130 | 58 |
| 32217 | 85 | 150 | 77 |
| 30218 | 90 | 160 | 65 |
| 31318 | 90 | 190 | 93 |
| 32018 | 90 | 140 | 64 |
| 32218 | 90 | 160 | 85 |
| 33018 | 90 | 140 | 78 |
| 32219 | 95 | 170 | 91 |
| 30220 | 100 | 180 | 74 |
| 31320 | 100 | 215 | 113 |
| 32020 | 100 | 150 | 64 |
| 32220 | 100 | 180 | 98 |
| 32021 | 105 | 160 | 70 |
| 30222 | 110 | 200 | 82 |
| 31322 | 110 | 240 | 126 |
| 32022 | 110 | 170 | 76 |
| 32222 | 110 | 200 | 112 |
| 33122 | 110 | 180 | 112 |
| 30224 | 120 | 215 | 87 |
| 31324 | 120 | 260 | 136 |
| 32024 | 120 | 180 | 76 |
| 32224 | 120 | 215 | 123 |
| 33024 | 120 | 180 | 96 |
| 30226 | 130 | 230 | 87.5 |
| 31326 | 130 | 280 | 144 |
| 32026 | 130 | 200 | 90 |
| 32226 | 130 | 230 | 135.5 |
| 32926 | 130 | 180 | 64 |
| 30228 | 140 | 250 | 91.5 |
| 31328 | 140 | 300 | 154 |
